Brakes
| Parking brake | Mechanical |
| Service brake | Hydraulic |
Dimensions
| Free lift | 5.4 in (14 cm) |
| Gradeability | 26% |
| Ground Clearance | 4.6 in (12 cm) |
| Height to Top of Overhead Guard | 7.2 ft (2 m) |
| Length to Fork Face | 9.2 ft (3 m) |
| Max Fork Height | 11 ft (3 m) |
| Overall Height - mast lowered | 7.2 ft (2 m) |
| Overall Width | 4.1 ft (1 m) |
| Right Angle Stack | 9.4 ft (3 m) |
| Turning Radius | 7.8 ft (2 m) |
| Wheelbase | 5.6 ft (2 m) |
Engine
| Battery | 12 V |
| Displacement | 136 cu in (0 m) |
| Engine Make | TOYOTA |
| Engine Model | 4Y - ECS - HP5 |
| Fuel Type | Gasoline |
| Number of Cylinders | 4 |
| Power | 57 hp (43 kw) |
| Power Measured @ | 2570 rpm |
| Torque | 118 lbs/ft |
| Torque Measured @ | 2200 rpm |
Toyota 8fgu30 For Sale
Hydraulic System
| Main pump flow standard | 21 gal/min (79 l/min) |
| Maximum operating pressure | 2275 psi |
MAST
Toyota 8fgcu30 Spec Sheet
| Lift Speed | 100 ft/min |
| Load Capacity | 6000 lbs (2,722 kg) |
| Lower Speed | 98 ft/min |
| Max Fork Spread | 9.9 in (25 cm) |
Operating Specifications
| Drawbar Pull | 4409.3 lbs (2,000 kg) |
| Fuel Capacity | 15.9 gal (60 l) |
| Max Speed | 11.2 mph (18 kph) |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Operating Weight | 9281.5 lbs (4,210 kg) |
| Tire Type | Pneumatic |
Tires
Toyota 8fgcu30 Manual
| Front Tires Size | 28 x 9-15-12PR (1) |
| Rear Tires Size | 6.50-10-10PR (1) |
